. . Support for 10th Generation Intel® Core i9 processors/Intel® Core i7 processors/Intel® Core i5 processors/Intel® Core i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1200 package. Caché L3 varía según la CPU. . (Por favor, acuda a ”lista de soporte de CPU” para más información.). .
.
Chipset.
. . Intel® H470 Express Chipset. . . .
.
Memoria.
. . Intel® Core i9/i7 processors:. Support for DDR4 2933/2666/2400/2133 MHz memory modules. Intel® Core i5/i3/Pentium®/Celeron® processors: . Support for DDR4 2666/2400/2133 MHz memory modules. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory. Arquitectura de memoria Dual Channel. Soporte para módulos de memoria ECC Un-buffered UDIMM 1Rx8/2Rx8 (operando en modo no-ECC). Soporte para módulos de memoria non-ECC Un-buffered DIMM 1Rx8/2Rx8. Soporte para módulos de memoria Extreme Memory Profile (XMP). . (Por favor diríjase a la ”Lista de memorias soportadas” para más información.). .
.
Gráfica Integrada.
Procesador gráfico integrado – Soporte Intel® HD Graphics. . 1 x puerto D-Sub, con una resolución máxima de 1920×1200@60 Hz. 1 x HDMI ports, supporting a maximum resolution of 4096×2160@30 Hz. * Support for HDMI 1.4 version and HDCP 2.3.. . Máxima memoria compartida de 512 MB. .
.
Audio.
. . Realtek® audio codec. Audio de alta definición. 2/4/5.1/7.1-channel. * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings >; Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software.. . . .
. . 1 x PCI Express x16, funcionando a x16. 2 x PCI Express x1 slots. (The PCI Express slots conform to PCI Express 3.0 standard.). . Supports up to ASPM L1.2 power management protocols.. .
.
Interfaz de almacenamiento.
. . 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support). 4 x conector SATA 6Gb/s. Soporta RAID 0, RAID 1, RAID 5, y RAID 10. Memoria Intel® Optane. . M.2 connectors support up to ASPM L1.2 PCIe power management protocols.. .
.
USB.
. . 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header). 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header). . . .
.
Conectores Internos E/S.
. . . 1 x 24-pin ATX main power connector. 1 x 8-pin ATX 12V power connector. 1 x CPU fan header. 1 x system fan header. 1 x RGB LED strip header. 4 x SATA 6Gb/s connectors. 1 x front panel header. 1 x front panel audio header. 1 x USB 3.2 Gen 1 header. 1 x USB 2.0/1.1 header. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only). 1 x serial port header. 1 x Clear CMOS jumper. . . . .
.
Panel E/S Trasero.
. . . 1 x PS/2 keyboard/mouse port. 1 x D-Sub port. 1 x HDMI port. 2 x USB 3.2 Gen 1 ports. 4 x USB 2.0/1.1 ports. 1 x RJ-45 port. 3 x audio jacks. . . . .
.
Controlador E/S.
. . Chip controlador E/S iTE®. . . .
.
. . . .
.
BIOS.
. . 1 x 256 Mbit flash. Licencia para uso de UEFI BIOS de AMI. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. . . .
